Description
Print speed of 150m2/h
The “Tx500-1800DS” is equipped with newly developed print heads (Six print heads with three staggered) and achieves print speed of 150 m2/h.
Expand your business opportunity with this improved print speed.
MDM-20 increases inkjet-ability and reduces ink costs
Tx500-1800DS
The Mimaki degassing module “MDM-20” eliminates the gasses or bubbles inside the ink. This means nozzle blockage is lessened and the accuracy of ink dot placement is improved. In addition, this module enables the printer to use undegassed bottled inks instead of conventional degassed ink packs, thereby reducing ink costs.
*MDM＝Mimaki Degassing Module
Continuous Print / enables increased productivity
Tension roller ensures stable feeding / take-up of polyester fabrics
The tension roller optimizes the tension of print fabrics and prevents loose media feed / take-up. Therefore, beautiful prints are assured. Moreover, “AMF”-system also ensures stable feeding /take-up of heavy rolled media by adjusting the tension.There is no need to constantly monitor the printer during high volume printing.
A built-in heater accelerates the drying time of printed media
A built-in heater accelerates the ink drying time by heating the media after printing. In addition, the external drying heater (optional) helps ink dry much faster. This reduces the occurrence of ink set-off, even during high-speed printing.
Mist absorption filter
The mist absorption fi lter prevents issues caused by ink mists and enhances the stability of print operations by suctioning the mist inside the printer and discharging it.
New sublimation ink “Sb300”
The sublimation ink “Sb300” will be simultaneously released with “Tx500-1800DS”. The “Sb300” ink offers a more affordable price than conventional ink. Furthermore, this ink produces brilliant color and dries fast.
Sublimation ink
Setting Roll-up media up to 60kg
Roll-up media of up to 60kg and 300mm in diameter can be used. There is no need to frequently change the media, meaning large orders can be handled smoothly and without interruption due to continuous printing.
Specifications
| Tx500-1800DS | ||
|---|---|---|
| Head | On-demand Piezo head （6 printheads with 3 staggered conformation） |
|
| Maximum width | 1,820 mm (71.7″) | |
| Print resolution | 300、450、600、900、1,200dpi | |
| The fastest print speed | 150㎡/h（300×300(HQ)dpi, 2 pass, Bi-directional, Normal speed, 4-color） | |
| Print mode | 4 color (Uni- / Bi-directional) |
300×300dpi, 300×300HQ, 300×450HQ, 600×600dpi, 600×900dpi, 600×1,200dpi |
| 6 color (Uni- / Bi-directional) |
300×300dpi, 300×300HQ, 600×450dpi, 600×600dpi, 600×900dpi, 600×1,200dpi | |
| Ink | Sublimation Ink Sb300, Sb320 | 6 color：Bl, M, Y, K, Lbl, Lm |
| Ink supply system | 2L bottle / each color | |
| Ink degassing module | Equipped with MDM-20 | |
| Media | Type | Pre-treated polyester fabrics |
| Width | Maximum: 1,910 mm (75.2″), Minimum: 297 mm (11.7″) | |
| Thickness | Up to 0.2 mm | |
| Weight | Up to 60 kg (132lbs) | |
| Print aspect | Outside | |
| Roll diameter | External: φ300mm (11.8″), Inside: φ76mm (3.0″) | |
| Drying device | Built-in back drying heater External drying heater (Optional) |
|
| Media take-up device | Roll take-up device, inside / outside selectable / 3 inch paper core | |
| Print gap | 1.5 mm～7.0 mm (Stepless adjustment) | |
| Interface | USB2.0 | |
| Applicable standard | VCCI class A, FCC class A, UL60950-1, RoHS directive CE Marking (EMC, Low voltage and Machinery directive), CB Report |
|
| Power speci fication | Single-phase AC 200～240 V, 20 A or under | |
| Power consumption | Less than 4,800W | |
| Operational environment | Temperature: 20°C-30°C (64-86 °F); Humidity: 35-65 % RH (non condensing) |
|
| Dimensions （W×D×H） | 3,830×1,440×1,700 mmm (150.8″×56.7″×66.9″) (*1) | |
| Weight | 750kg (1,653lbs) | |
※1 Ink supply unit is not included in the dimensions.
Ink set
| Sb300 ［Bl,M,Y,K,Lbl,Lm］ |
Bl M Y K |
|---|---|
| Bl M Y K Lbl Lm | |
| Sb320 ［Bl,M,Y,K,Lbl,Lm］ |
Bl M Y K |
| Bl M Y K Lbl Lm |
- Some of the samples in this website are artificial renderings.
- Specifications, design and dimensions stated in this website may be subject to change without notice (for technical improvements, etc).
- The corporate names and merchandise names written on this website are the trademark or registered trademark of the respective corporations.
- Inkjet printers print using extremely fine dots, so colors may very slightly vary after replacement of the printing heads. Also note that if using multiple printer units, colors could vary slightly from one unit to other unit due to slight individual differences.
